Bobcat E35 Compact Excavator Information
Available in Standard, Long, and Extendable Arm
Part of the R-Series, the Bobcat® E35 compact (mini) excavator is a popular choice in the 3-ton size class. Zero Tail Swing (ZTS) provides unrestricted rotation, greater flexibility and reduced potential for damage to the machine and surrounding property. It’s available with an angle blade option, long arm option or clamp-ready extendable arm option. Upgrade to an Optional 33 hp engine for even more productivity.
| EMISSIONS TIER (EPA) | Tier 4 |
| ENGINE FUEL | diesel |
| MAXIMUM GOVERNED RPM | 2,550 rpm |
| HORSEPOWER | 24.8 hp |
| TURBOCHARGED ENGINE | not-available |
| OPTIONAL HORSEPOWER | n/a |
Performance
| OPERATING WEIGHT | 8,377 lb |
| WEIGHT CLASS | 3.8 t |
| TRAVEL SPEED | 2.9 mph |
| TRAVEL SPEED - HIGH | 2.9 mph |
| TRAVEL SPEED - LOW | 1.6 mph |
| ARM DIGGING FORCE | 3,986 lbf |
| BUCKET DIGGING FORCE | 6,968 lbf |
| RATED LIFT CAPACITY | 3130 lb |
| LIFT RADIUS | 118 in |
| BOOM SWING - LEFT | 75° |
| BOOM SWING - RIGHT | 55° |
| MAXIMUM DIG DEPTH | 11.2 ft |
| MAXIMUM DUMP HEIGHT | 11.6 ft |
Capacities
Hydraulic System
| AUXILIARY STD FLOW | 16.9 gal/min |
| AUXILIARY PRESSURE | 2,987 psi |
Dimensions
| LENGTH | 190.3 in |
| WIDTH | 69 in |
| HEIGHT | 96.2 in |
| HEIGHT WITH OPERATOR CAB | 96.2 in |
| REACH @ MAXIMUM HEIGHT | 18.1 ft |
List of Features
| AIR CONDITIONING | Optional |
| CAB ENCLOSURE | optional |
| CAB HEATER | optional |
| HEATER / AIR CONDITIONING | optional |
| TAIL SWING TYPE | zero |
| ENGINE SHUTDOWN | standard |
| AUXILIARY HYDRAULICS | standard |
| SECONDARY AUXILIARY HYDRAULICS | optional |
| RUBBER TRACK | standard |
| SELECTABLE AUXILIARY HYDRAULIC FLOW | standard |
| ANGLE BLADE | optional |
| QUICK TACH SYSTEM | standard |
