Multiquip ST41230 / ST41460

Multiquip ST41230 / ST41460

Multiquip ST41230 / ST41460 Information

4 Inch Discharge, 230/460 three-phase, 60 Hz 10 HP, 423GPM, 138ft Total Head

10.0HP, 230/460V, three-phase, 60 Hz.
Running AMPS : 28.6A (230V) / 14.3A (460V).
FLOW Capacity: 423 GPM.
HEAD: 138’.
Pump Diameter: 12.5”
Weight: 205 lbs.
Passes up to .6” spherical solids.
4” NPT Male Discharge Port.
Reliable double mechanical oil-filled seals.
Easy Impeller Clean-out.
Output shaft is heat-treated 410 Stainless Steel.
Suction Strainer:  Stainless Steel (304).
Pumps Liquid up to 140° F – pH 4-10.
33’ of molded power cord w/strain relief.
Optional Control Box Model: CB1269 for 230V
Optional Control Box Model: CB1456 for 460V

Engine

HORSEPOWER10 HP

Performance

IMPELLER TYPEHigh Chrome Steel
IMPELLER DISC SIZE4 in
TOTAL HEAD138 ft
MAX SOLID INTAKE.6 in
PHASEThree
STARTING AMPERAGE230V/172. A / 460V/85.8 A
RUNNING AMPERAGE230V/28.6A / 460V/14.3 A
CABLE LENGTH33 ft
PUMP DIAMETER12.5 in
VOLTAGE230/460 V
OPERATING WEIGHT205 lb

Capacities

HEIGHT32 in

List of Features

  • View description for list of features...
*New price, if shown, is Suggested List Price (SLP). Current national programs are subtracted. SLP and/or final actual sales price will vary depending on options or accessories selected.
REQUEST A QUOTE
Contact A Sales Professional
Manufacturer Multiquip
Category Water Pumps & Trailers
Subcategory Submersible Pumps
Model ST41230 / ST41460
Condition New
Horsepower 10 HP
