Bobcat PA750P Towable Air Compressor

The Bobcat® PA750P portable air compressor is designed for productivity and durability, with safe and easy jobsite serviceability to keep you up and running when it matters most.

  • Engineered for easy serviceability for maximum uptime
  • Ideal for foundation drilling, mining, and oil & gas applications
  • Can be equipped with the IQ System® for cleaner and drier air

350 psig

Operating Pressure

8 h

Runtime

750 cfm

Free Air Delivery

Portable Power Equipment Special Offers

As low as 0% for 36 months* on select portable power products or low lease payments.

Bobcat PA750P Towable Air Compressor Features

Precision Rotors

Precision Rotors

The rotors used in Bobcat proprietary aigearsrends feature a versatile gearbox design with case carburized gears, providing a wide gear ratio range. Premium bearings also add greater durability and improve operational efficiency.

FlexAir System

FlexAir System

Bobcat compressors, featuring the variable FlexAir System, let you maintain complete control of both air pressure and airflow. From the control panel, you can dial in the exact combination of pressure and flow within the compressor’s operational range.

Dual Pressure Capability

Dual Pressure Capability

Dual pressure compressors offer two-in-one versatility with clear HI/LOW options on the control panel. Operators can select between two adjustable airflow and air pressure combinations to power multiple applications, eliminating the need for multiple compressors.

Proprietary Airends

Proprietary Airends

With tighter rotor tolerances comes better performance. Bobcat proprietary airends are engineered to deliver exceptional performance, low vibration and reduced noise, and they’re manufactured at our state-of-the-art facility in Statesville, North Carolina.

Bobcat PA750P Towable Air Compressor Specs

** Listed specs based on machine base model. Actual specs may vary depending on model and options **

Specifications

Rated Operating Pressure 350 psig (24.1 bar)
Fuel Tank Capacity 128 gal
Pressure Range 140-365 psig (9.7-25.1 bar)
Air Discharge Outlet Size 3 in

Performance

Rated Speed 1800 rpm
Idle Speed 1,350 rpm
Shipping Weight with Running Gear 11,023 lb
Operating Weight with Running Gear 12,015 lb
Shipping Weight without Running Gear 9,855 lb
Operating Weight without Running Gear 11,177 lb
Engine Make Cummins
Emissions Tier Level Tier 4 Final (T4F)
Displacement 543 in³
System Voltage 24 V

Dimensions

Length with Running Gear 226.6 in
Width with Running Gear 82.6 in
Height with Running Gear 101.3 in
Track Width with Running Gear 68.2 in
Tire Size with Running Gear 16 in
Length without Running Gear 171 in
Width without Running Gear 83 in
Height without Running Gear 95 in
